Dorman 22-1009HD Suspension - Leaf Spring

In stock
SKU: 591|221009HD
Confirm Fitment Before You Buy
Not sure it fits? Message Year/Make/Model/Engine (2WD/4WD if applicable) and we’ll help confirm compatibility.
Why buy from Koskowski Automotive?
• 50+ years (since 1972) • Dorman Authorized Seller • Fast shipping • Easy returns
$415.96
Vehicle Fitment: Use the table below to match your exact configuration. If you don’t see your exact setup, message us before ordering.

Product details

  • SKU 591|221009HD
  • Barcode #N/A

Share this item!

Description

Product Description

Properly functioning leaf springs hold the weight and payload of a vehicle or trailer and are essential to suspension performance and passenger comfort. Check the product attributes to select the right leaf spring for your application.

  • Direct replacement - these leaf springs are designed to match the fit and function of the original leaf springs on specific vehicles or trailers
  • Ideal solution - seamlessly replaces leaf springs damaged by overloading, collision, cracking or corrosion, or are due for replacement
  • Durable construction - made from quality materials to strict specifications to ensure reliable performance and long service life
  • Trustworthy quality - engineered, manufactured and supported by the premier aftermarket leaf spring provider in the USA

Detailed Applications

Year Make Model Configuration Positions Application Notes
2002 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
2002 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
2001 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
2001 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
2000 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
2000 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1999 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1999 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1998 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1998 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1997 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1997 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1996 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1996 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1995 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1995 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1994 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1994 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1993 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1993 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1992 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1992 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1991 Chevrolet C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design
1991 GMC C3500HD Rear 8 Leaf; 5,000 Lb. Average Capacity; 4 In. Pack Thickness; Heavy Duty Aftermarket Design

Product Specifications

Axle Modification Needed: No
Axle Orientation: Rear
Bushing Color: Black
Bushings Included: Yes
Color: Black
End 1 Attachment Type: Berlin Eye
End 2 Attachment Type: Berlin Eye
Helper Spring: No
Leaf Quantity: 8
Leaf Spring Arch Length: 4.625 in
Leaf Width: 3 in
Length Axis 1: 28 in
Length Axis 2: 28 in
Length B: 28 in
Load Rate: 5000 lb
Material: Steel
Mounting Hardware Included: No
Pack Thickness: 4 in
Package Contents: 1 Leaf Spring
Package Quantity: 1
Packaging Type: Box
Spring Arch Length: 4.625 in
Spring Research Institute Number: 22-1009HD
Suspension Grade Type: Heavy Duty

OE Numbers

NON-DIRECT OE CROSS
12387666 GENERAL MOTORS
15636134 GENERAL MOTORS
