Product Description
Oil pan leaking? This engine oil pan is precision-engineered to match the original equipment pan on specific vehicle years, makes and models for a reliable replacement.
- Direct replacement - this engine oil pan is made to match the original pan on specific vehicles
- Complete assembly - includes replacement pan and drain plugs to match original components
- Durable design - high-strength coating prevents future corrosion
- Trustworthy value - backed by team of engineers and quality control experts in the United States
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2011 | Chevrolet | Aveo | L4 98 1.6L (1598cc); Engine Desg. LXV | ||
| 2011 | Chevrolet | Aveo5 | L4 98 1.6L (1598cc) | ||
| 2010 | Chevrolet | Aveo | L4 98 1.6L (1598cc); Engine Desg. LXV | ||
| 2010 | Chevrolet | Aveo5 | L4 98 1.6L (1598cc) | ||
| 2010 | Pontiac | G3 | L4 98 1.6L (1598cc); Engine Desg. LXV | ||
| 2009 | Chevrolet | Aveo | L4 98 1.6L (1598cc); Engine Desg. LXV | ||
| 2009 | Chevrolet | Aveo5 | L4 98 1.6L (1598cc) | ||
| 2009 | Pontiac | G3 | L4 98 1.6L (1598cc); Engine Desg. LXV | ||
| 2009 | Pontiac | G3 Wave | L4 98 1.6L (1598cc); Engine Desg. LXV |
Product Specifications
| Baffled: | No |
|---|---|
| Capacity: | 4.8 qt |
| Color: | Metallic Gray |
| Crank Shaft Wiper Included: | No |
| Dipstick Port: | Yes |
| Drain Plug Included: | Yes |
| Drain Thread Size: | M12-1.75 |
| Engine Oil Cooler Return Fitting: | No |
| Gasket Or Seal Included: | No |
| Installation Hardware Included: | No |
| Kick Out Type Pan: | No |
| Length: | 17.31 in |
| Material: | Aluminum |
| Maximum Depth: | 6.56 in |
| Maximum Width: | 12 in |
| Minimum Depth: | 6.43 in |
| Oil Level Sensor Port: | No |
| Package Contents: | Oil Pan |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Pickup Included: | No |
| Pump Type: | Hydraulic |
| Sump Location: | Center |
| Sump Type: | Wet |
| Windage Tray Included: | No |
OE Numbers
| NON-DIRECT OE CROSS | |
|---|---|
| 25181235 | GENERAL MOTORS |
| 96970445 | GENERAL MOTORS |
