Product Description
Oil pan leaking? This engine oil pan is precision-engineered to match the original equipment pan on specific vehicle years, makes and models for a reliable replacement.
- Direct replacement - this engine oil pan is made to match the original pan on specific vehicles
- Complete assembly - includes replacement pan and drain plugs to match original components
- Durable design - high-strength coating prevents future corrosion
- Trustworthy value - backed by team of engineers and quality control experts in the United States
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2009 | Buick | Allure | V6 231 3.8L (3800cc) | ||
| 2009 | Buick | LaCrosse | V6 231 3.8L (3800cc) | ||
| 2008 | Buick | Allure | V6 231 3.8L (3800cc) | ||
| 2008 | Buick | LaCrosse | V6 231 3.8L (3800cc) | ||
| 2008 | Buick | Lucerne | V6 231 3.8L (3800cc) | ||
| 2008 | Pontiac | Grand Prix | V6 231 3.8L (3800cc) | ||
| 2007 | Buick | Allure | V6 231 3.8L (3800cc) | ||
| 2007 | Buick | LaCrosse | V6 231 3.8L (3800cc) | ||
| 2007 | Buick | Lucerne | V6 231 3.8L (3800cc) | ||
| 2007 | Pontiac | Grand Prix | V6 231 3.8L (3800cc) | ||
| 2006 | Buick | Allure | V6 231 3.8L (3800cc) | ||
| 2006 | Buick | LaCrosse | V6 231 3.8L (3800cc) | ||
| 2006 | Buick | Lucerne | V6 231 3.8L (3800cc) | ||
| 2006 | Pontiac | Grand Prix | V6 231 3.8L (3800cc) | ||
| 2005 | Buick | Allure | V6 231 3.8L (3800cc) | ||
| 2005 | Buick | LaCrosse | V6 231 3.8L (3800cc) | ||
| 2005 | Pontiac | Grand Prix | V6 231 3.8L (3800cc) |
Product Specifications
| Baffled: | Yes |
|---|---|
| Capacity: | 4.5 qt |
| Color: | Metallic Gray |
| Crank Shaft Wiper Included: | No |
| Dipstick Port: | No |
| Drain Plug Included: | Yes |
| Drain Thread Size: | M12-1.75 |
| Engine Oil Cooler Return Fitting: | No |
| Gasket Or Seal Included: | No |
| Installation Hardware Included: | No |
| Kick Out Type Pan: | No |
| Length: | 17.70 in |
| Material: | Aluminum |
| Maximum Depth: | 5.937 in |
| Maximum Width: | 9.25 in |
| Minimum Depth: | 5.125 in |
| Oil Level Sensor Port: | Yes |
| Package Contents: | Oil Pan |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Pickup Included: | No |
| Pump Type: | Hydraulic |
| Sump Location: | Center |
| Sump Type: | Wet |
| Windage Tray Included: | No |
OE Numbers
| NON-DIRECT OE CROSS | |
|---|---|
| 12581549 | GENERAL MOTORS |
| 12597244 | GENERAL MOTORS |
