Dorman 264-267 Engine Oil Pan
Regular price
$206.75
Couldn't load pickup availability
Product Description
Oil pan leaking? This engine oil pan is precision-engineered to match the original equipment pan on specific vehicle years, makes and models for a reliable replacement.
- Direct replacement - this engine oil pan is made to match the original pan on specific vehicles
- Complete assembly - includes replacement pan and drain plugs to match original components
- Durable design - high-strength coating prevents future corrosion
- Trustworthy value - backed by team of engineers and quality control experts in the United States
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2021 | Chevrolet | Beat (Mexico) | L4 74 1.2L (1206cc) | ||
| 2020 | Chevrolet | Beat (Mexico) | L4 74 1.2L (1206cc) | ||
| 2019 | Chevrolet | Beat (Mexico) | L4 74 1.2L (1206cc) | ||
| 2018 | Chevrolet | Beat (Mexico) | L4 74 1.2L (1206cc) | ||
| 2017 | Chevrolet | Spark Classic (Mexico) | L4 74 1.2L (1206cc) | ||
| 2016 | Chevrolet | Spark Classic (Mexico) | L4 74 1.2L (1206cc) | ||
| 2015 | Chevrolet | Spark | L4 74 1.2L (1206cc) | ||
| 2015 | Chevrolet | Spark | L4 76 1.2L (1249cc) | ||
| 2014 | Chevrolet | Spark | L4 74 1.2L (1206cc) | ||
| 2014 | Chevrolet | Spark | L4 76 1.2L (1249cc) | ||
| 2013 | Chevrolet | Spark | L4 74 1.2L (1206cc) | ||
| 2013 | Chevrolet | Spark | L4 76 1.2L (1249cc) | ||
| 2012 | Chevrolet | Spark (Mexico) | L4 61 1.0L (995cc); CV48 Body Code | 2nd Design; From 11/01/11 | |
| 2012 | Chevrolet | Spark (Mexico) | L4 74 1.2L (1206cc) | ||
| 2011 | Chevrolet | Spark (Mexico) | L4 74 1.2L (1206cc) |
Product Specifications
| Baffled: | Yes |
|---|---|
| Capacity: | 4 qt |
| Color: | Black |
| Crank Shaft Wiper Included: | No |
| Dipstick Port: | No |
| Drain Plug Included: | Yes |
| Drain Thread Size: | M12 X 1.75 |
| Engine Oil Cooler Return Fitting: | No |
| Gasket Or Seal Included: | No |
| Installation Hardware Included: | No |
| Kick Out Type Pan: | No |
| Length: | 15.5 in |
| Material: | Steel |
| Maximum Depth: | 6.125 in |
| Maximum Width: | 8.312 in |
| Minimum Depth: | 5.437 in |
| Oil Level Sensor Port: | No |
| Package Contents: | 1 Oil Pan |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Pickup Included: | No |
| Pump Type: | Hydraulic |
| Sump Location: | Front |
| Sump Type: | Wet |
| Windage Tray Included: | No |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 25186958 | GENERAL MOTORS |
| 25189002 | GENERAL MOTORS |
