Dorman 523-602 Suspension - Control Arm Bushing
Confirm Fitment Before You Buy
Not sure it fits? Message Year/Make/Model/Engine (2WD/4WD if applicable) and we’ll help confirm compatibility.
Why buy from Koskowski Automotive?
• 50+ years (since 1972) • Dorman Authorized Seller • Fast shipping • Easy returns
Regular price
$21.73
Couldn't load pickup availability
Vehicle Fitment: Use the table below to match your exact configuration. If you don’t see your exact setup, message us before ordering.
Product Description
This suspension control arm bushing is precision-engineered and rigorously tested to provide reliable replacement for the original equipment on specific vehicles.
- Direct replacement - fits and performs like the original equipment bushing on specific vehicles
- Reliable fit - precision-engineered to match the design and dimensions of original components
- Durable construction - manufactured to strict standards using sturdy, safe materials
- Rigorously tested - thorough quality control measures ensure longevity
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2001 | Chevrolet | Metro | Front Lower Forward | ||
| 2001 | Suzuki | Swift | Front Lower Forward | ||
| 2000 | Chevrolet | Metro | Front Lower Forward | ||
| 2000 | Pontiac | Firefly | Front Lower Forward | ||
| 2000 | Suzuki | Swift | Front Lower Forward | ||
| 1999 | Chevrolet | Metro | Front Lower Forward | ||
| 1999 | Pontiac | Firefly | Front Lower Forward | ||
| 1999 | Suzuki | Swift | Front Lower Forward | ||
| 1998 | Chevrolet | Metro | Front Lower Forward | ||
| 1998 | Pontiac | Firefly | Front Lower Forward | ||
| 1998 | Suzuki | Swift | Front Lower Forward | ||
| 1997 | Geo | Metro | Front Lower Forward | ||
| 1997 | Pontiac | Firefly | Front Lower Forward | ||
| 1997 | Suzuki | Swift | Front Lower Forward | ||
| 1996 | Geo | Metro | Front Lower Forward | ||
| 1996 | Pontiac | Firefly | Front Lower Forward | ||
| 1996 | Suzuki | Swift | Front Lower Forward | ||
| 1995 | Geo | Metro | Front Lower Forward | ||
| 1995 | Pontiac | Firefly | Front Lower Forward | ||
| 1995 | Suzuki | Swift | Front Lower Forward |
Product Specifications
| Bracket Included: | No |
|---|---|
| Bushing 1 Width: | 66.2 mm |
| Bushing Material: | Steel; Rubber |
| Color: | Black |
| Color Code: | Grey |
| Distance Between Mounting Holes: | 62.8 mm |
| Dust Boot Included: | No |
| Grade Type: | Regular |
| Hardware Included: | No |
| Height: | 66.2 mm |
| Inside Diameter: | 12.2 mm |
| Item Grade: | Regular |
| Length: | 60 mm |
| Material: | Rubber |
| Mounting Hardware Included: | No |
| Mounting Hole Diameter: | 18.4 mm |
| Mounting Type: | Bushing |
| Outside Diameter: | 60 mm |
| Package Contents: | Bushing |
| Packaging Type: | Box |
| Wall Thickness: | 23.8 mm |
| Width: | 60 mm |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 91173755 | GENERAL MOTORS |
| NON-DIRECT OE CROSS | |
|---|---|
| 45201-50G00 | SUZUKI |
| 4520150G10 | SUZUKI |
| 45202-50G00 | SUZUKI |
| 4520250G10 | SUZUKI |
| 91173753 | GENERAL MOTORS |
| 91173754 | GENERAL MOTORS |
