Dorman 626-711 HVAC Heater Hose Assembly
Regular price
$0.00
Couldn't load pickup availability
Product Description
This replacement HVAC heater hose assembly is engineered to match the fit and durability of the stock heater hose assembly on specified vehicles. It is designed to withstand extreme temperature changes to extend service life.
- Ideal replacement - this HVAC heater hose assembly directly replaces the original heater hose on specified vehicle years, makes and models
- Durable construction - this part is specifically designed to withstand extreme temperature changes and resist cracking and leaking
- Cost-effective and reliable - offers original manufacturer quality at lower cost than getting replacement at dealer
- Industry-leading design - professionally engineered by the aftermarket leader in heater hose assemblies
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2021 | Ram | ProMaster 1500 | Inlet | Heater Hose | |
| 2021 | Ram | ProMaster 2500 | Inlet | Heater Hose | |
| 2021 | Ram | ProMaster 3500 | Inlet | Heater Hose | |
| 2020 | Ram | ProMaster 1500 | Inlet | Heater Hose | |
| 2020 | Ram | ProMaster 2500 | Inlet | Heater Hose | |
| 2020 | Ram | ProMaster 3500 | Inlet | Heater Hose | |
| 2019 | Ram | ProMaster 1500 | Inlet | Heater Hose | |
| 2019 | Ram | ProMaster 2500 | Inlet | Heater Hose | |
| 2019 | Ram | ProMaster 3500 | Inlet | Heater Hose |
Product Specifications
| Axis 1 Length: | 1525 mm |
|---|---|
| Axis 2 Length: | 537 mm |
| Branch Quantity: | 2 |
| Burst Pressure: | 75 PSI |
| Centerline Length: | 2062 mm |
| Clamps Included: | No |
| Color: | Black; Natural |
| Contains Spring: | No |
| Coolant Hose Heat Shield Included: | No |
| Coolant Hose Type: | Branched |
| End 1 Attachment Type: | Hose |
| End 1 Inside Diameter: | 14.75 mm |
| End 1 Type: | Hose |
| End 2 Attachment Type: | Hose |
| End 2 Inside Diameter: | 7 mm |
| End 2 Type: | Hose |
| End 3 Attachment Type: | Hose |
| End 3 Inside Diameter: | 16.75 mm |
| Grade Type: | Regular |
| Heat Shield Included: | No |
| Hose Attachment End 1: | Flared Tube |
| Hose Attachment End 2: | Flared Tube |
| Hose End (1) Outside Diameter (In): | 21.75 mm |
| Hose End (2) Outside Diameter (In): | 14 mm |
| Hose End (3) Outside Diameter (In): | 23.75 mm |
| Hose Material: | EPDM; Metal; Plastic |
| Hose Outside Diameter: | 16 |
| Hose Overall Length (In): | 1525 mm |
| Hose Quantity: | 1 |
| Hose Shape: | Molded Assembly |
| Inside Diameter: | 14 mm |
| Length: | 1525 mm |
| Material: | EPDM; Metal; Plastic |
| Maximum Bend Angle: | 115 deg |
| Maximum Working Pressure: | 100 PSI |
| Modular: | Branch |
| Modular Components Included: | Yes |
| Molded: | Yes |
| Mounting Bracket Included: | Yes |
| Outside Diameter: | 16 mm |
| Package Contents: | Heater Hose Assembly |
| Package Quantity: | 1 |
| Packaging Type: | Bag |
| Protective Sleeve Attached: | No |
| Protective Sleeve Included: | No |
| Quick Connect Fitting Quantity: | 0 |
| Thermostatically Controlled: | No |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 52014853AC | CHRYSLER |
