Dorman 630-003 Axle Shaft Assembly
Regular price
$0.00
Couldn't load pickup availability
Product Description
Axle shaft damaged or bearings worn out? This axle shaft assembly directly replaces the original equipment on certain vehicles, ready for install right out of the box.
- Direct replacement - this axle shaft assembly replaces the original equipment on specific vehicle years, makes and models
- Ready to install - comes pre-assembled for simple installation with no further assembly required
- Durable construction - designed to rigorous standards and tested to ensure performance
- Trustworthy solution - backed by team of engineers and quality control specialists in the United States
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2013 | Ram | 2500 | 4WD | Front Left | w/U Joint Assembly |
| 2013 | Ram | 3500 | Cab and Chassis; 4WD | Front Left | w/U Joint Assembly |
| 2012 | Ram | 2500 | 4WD | Front Left | w/U Joint Assembly |
| 2012 | Ram | 3500 | 4WD | Front Left | w/U Joint Assembly |
| 2011 | Ram | 2500 | 4WD | Front Left | w/U Joint Assembly |
| 2011 | Ram | 3500 | 4WD | Front Left | w/U Joint Assembly |
| 2010 | Dodge | Ram 2500 | 4WD | Front Left | w/U Joint Assembly |
| 2010 | Dodge | Ram 3500 | 4WD | Front Left | w/U Joint Assembly |
Product Specifications
| ABS Tone Ring Included: | No |
|---|---|
| Adjustable: | No |
| Axle Shaft Seal Included: | No |
| Brake Backing Plate Included: | No |
| Brake Dust Shield Included: | No |
| Brake Hardware Included: | No |
| Compressed Length: | 684.9 mm |
| Differential Case Design Type: | Front Differential |
| Grade Type: | Regular |
| Hub Bearing Included: | No |
| Inboard Spline Quantity: | 33 |
| Length: | 684.9 mm |
| Material: | Carbon Steel |
| Outboard Spline Quantity: | 35 |
| Package Contents: | 1 Axle Shaft |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Rust Resistant Coating: | No |
| Selling Package Quantity UOM: | Piece |
| Shaft Diameter: | 38 mm |
| Shaft Length: | 684.9 mm |
| Shaft Material: | Carbon Steel |
| Wheel Studs Included: | No |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 68065427AB | CHRYSLER |
