Dorman 686-257 Steering - Knuckle Kit

In stock
SKU: 591|686257
Confirm Fitment Before You Buy
Not sure it fits? Message Year/Make/Model/Engine (2WD/4WD if applicable) and we’ll help confirm compatibility.
Why buy from Koskowski Automotive?
• 50+ years (since 1972) • Dorman Authorized Seller • Fast shipping • Easy returns
Regular price $219.74
Vehicle Fitment: Use the table below to match your exact configuration. If you don’t see your exact setup, message us before ordering.

Product details

  • SKU 591|686257
  • Barcode 889245539571

Product Description

Fixing a worn wheel bearing would traditionally require a difficult procedure using a hydraulic press, or purchasing multiple components. This Dorman OE FIX loaded knuckle includes all critical components already assembled for a fast, simple, safe install. For repair shops, that makes it less likely that you will have a vehicle stuck in the service bay. For vehicle owners, that makes this formerly complex job requiring special equipment much easier.

  • Pre-pressed assembly - this complete loaded knuckle kit includes all necessary components ready for installation right out of the box
  • Saves hours - eliminates the possibility of extended time spent wrestling with individual corroded components
  • Simpler solution - no need for hydraulic press to perform complete bearing repair, making replacement faster and more predictable for both professionals and DIYers
  • Quality engineering - designed in the United States and backed by a century of automotive aftermarket experience

Detailed Applications

Year Make Model Configuration Positions Application Notes
2006 Toyota Camry L4 2.4L (2362cc) Front Left Built in Japan; Loaded Knuckle; Includes Hub, Bearing, and Dust Shield
2005 Toyota Camry L4 2.4L (2362cc) Front Left Built in Japan; Loaded Knuckle; Includes Hub, Bearing, and Dust Shield
2004 Toyota Camry L4 2.4L (2362cc) Front Left Built in Japan; Loaded Knuckle; Includes Hub, Bearing, and Dust Shield

Product Specifications

Anti Lock Brake Sensor Included: No
Anti Lock Braking System: Yes
Anti Lock Braking System Type: Sensor
Axle Included: No
Bolt Circle Diameter: 114 mm
Brake Pilot Diameter: 62 mm
Color: Black
Connector Quantity: 0
Connector Terminal Quantity: 0
Finish: Painted
Flange Bolt Hole Diameter: 17.95 mm
Flange Bolt Hole Quantity: 5
Flange Bolts Included: No
Flange Diameter: 139 mm
Flange Included: Yes
Flange Offset: 22.9 mm
Flange Shape: Circular
Grade Type: Standard
Hub Included: Yes
Hub Pilot Diameter: 34 mm
Instruction Manual Included: No
Material: Steel
Mounting Hardware Included: No
Package Contents: 1 Hub
Package Contents: 1 Loaded Knuckle; 1 Axle Nut; 2 Dust Deflectors
Package Quantity: 1
Packaging Type: Box
Selling Package Quantity UOM: Piece
Spline Quantity: 26
Spline Quantity: 0
Wheel Pilot Diameter: 60 mm
Wheel Stud Quantity: 0
Wheel Stud Size: M12-1.5
Wheel Studs Included: No

OE Numbers

NON-DIRECT OE CROSS
4321258010 TOYOTA
43212AA010 TOYOTA
43502-28090 TOYOTA
43502-AA011 TOYOTA
4778228230 TOYOTA
90080-36193 TOYOTA
9036945003 TOYOTA
