Dorman 692-255 Fuel Tank Sending Unit
Regular price
$550.35
Couldn't load pickup availability
Product Description
This fuel tank sending unit is designed to match the fit and function of the original unit on specified applications. Made of quality materials, it is engineered for reliable performance and durability.
- Direct replacement - this fuel tank sending unit is designed to match the fit and function of the original unit on specified applications
- Restores functionality - reliable replacement for an original part that has failed due to internal sensor failure
- Durable construction - this part is made from quality materials to ensure reliable performance and long service life
- Trustworthy quality - backed by team of product experts in the United States and more than a century of automotive experience
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2003 | Ford | F-250 Super Duty | V8 445 7.3L | ||
| 2003 | Ford | F-350 Super Duty | V8 445 7.3L | ||
| 2002 | Ford | F-250 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 2002 | Ford | F-350 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 2001 | Ford | F-250 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 2001 | Ford | F-350 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 2000 | Ford | F-250 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 2000 | Ford | F-350 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 1999 | Ford | F-250 Super Duty | V8 445 7.3L | Mid-Ship Tank | |
| 1999 | Ford | F-350 Super Duty | V8 445 7.3L | Mid-Ship Tank |
Product Specifications
| Adjustable Float Level: | Yes |
|---|---|
| Connector Color: | Black |
| Connector Gender: | Male |
| Connector Quantity: | 1 |
| Connector Shape: | Round |
| Fuel Pump Included: | No |
| Gasket Or Seal Included: | Yes |
| Inlet Attachment Type: | Hose Barb |
| Inlet Diameter: | 5 mm |
| Inlet Fitting Thread Size: | No Thread |
| Inlet Quantity: | 1 |
| Length: | 385 mm |
| Lock Ring Included: | No |
| Ohms Empty: | 15 Ohms |
| Ohms Full: | 160 Ohms |
| Outlet Attachment Type: | Hose Barb |
| Outlet Diameter: | 5.7 mm |
| Outlet Fitting Thread Size: | No Thread |
| Outlet Quantity: | 1 |
| Outside Diameter: | 160 mm |
| Package Contents: | 1 Sending Unit; 1 Gasket |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Plug/Connector Type: | Male |
| Pump Included: | Yes |
| Resistance Ohms Empty: | 15 Ohms |
| Resistance Ohms Full: | 160 Ohms |
| Strainer Included: | Yes |
| Tank Seal Outside Diameter: | 160 mm |
| Terminal Quantity: | 2 |
| Terminal Type: | Pin |
| Vent Quantity: | 0 |
| Wire Colors: | Red; Yellow |
| Wire Gauge Measurement: | 20 AWG |
| Wire Quantity: | 2 |
| Wiring Harness Included: | Yes |
| Wiring Harness Length: | 460 mm |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| F81Z9275AA | FORD MOTOR COMPANY |
| F81Z9275AH | FORD MOTOR COMPANY |
| F81Z9275AJ | FORD MOTOR COMPANY |
| PS125 | FORD MOTOR COMPANY |
| PS175 | FORD MOTOR COMPANY |
