Dorman 924-5820 Air Tank Assembly 01-18 Volvo VNL VNM VN 8075917
Confirm Fitment Before You Buy
Not sure it fits? Message Year/Make/Model/Engine (2WD/4WD if applicable) and we’ll help confirm compatibility.
Why buy from Koskowski Automotive?
• 50+ years (since 1972) • Dorman Authorized Seller • Fast shipping • Easy returns
Regular price
$220.27
Select your vehicle at the top of the page to check fitment.
Couldn't load pickup availability
Vehicle Fitment: Use the table below to match your exact configuration. If you don’t see your exact setup, message us before ordering.
Maintain the effectiveness of air-actuated braking and suspension systems by replacing a corroded or leaking air tank with a new reservoir. Designed to fit like the original equipment tank with same port configurations.
- Direct replacement - this air reservoir features the same port configuration and physical dimensions as the original tank
- Quality construction - this tank is made with precise port locations and finished in a corrosion-resistant coating inside and outside
- Validation tested - has been salt spray chamber tested internally and externally to meet or exceed industry standard for corrosion resistance
- Excellent value - original equipment quality at a lower cost
Vehicle Fitment
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2004 | Volvo | VN | ||
| 2001-2018 | Volvo | VNL | ||
| 2016-2017 | Volvo | VNL 300 | ||
| 2017 | Volvo | VNL 400 | ||
| 2015-2016 | Volvo | VNL 430 | ||
| 2015-2016 | Volvo | VNL 630 | ||
| 2015-2016 | Volvo | VNL 670 | ||
| 2017 | Volvo | VNL 740 | ||
| 2017 | Volvo | VNL 760 | ||
| 2017 | Volvo | VNL 860 | ||
| 2001-2018 | Volvo | VNM |
Please confirm the part number and your vehicle's year, make, model and engine before ordering. Questions? Message us with your VIN and we'll check fitment for you.
Specifications
| Brand | Dorman |
|---|---|
| Part Number | 924-5820 |
| UPC | 889245188045 |
| Material | Carbon Steel |
| Length | 29.5 in. |
| Color | Black |
| Mounting Hardware Included | No |
| Diameter | 10 in. |
| Mounting Hole Quantity | 0 |
| Capacity | 35 Lt |
| Material Thickness | 0.13 in. |
| Air Tank Type | Tractor |
| Diameter (B) | 10 in |
| Length (A) | 29.5 in |
| Maximum Working Pressure | 150 PSI |
| Mounting Type | Strap On |
| Number of Chambers | 1 in. |
| Package Contents | 1 Air Tank |
| Port Quantity | 7 |
| Port Thread Diameter | 1/4 in; 1/2 in |
| Port Thread Pitch | 1.5 mm |
| Tank Chamber Quantity | 1 |
| Thread Size | 22 m; 1/4 in |
| Threaded Mounting Bracket Included | No |
| Valve Included | No |
| Volume | 35 L |
| Country of Origin | India |
| Warranty | Limited Lifetime |
OE & Interchange Numbers
| 8075917 | Volvo (OE) |
|---|---|
| 172.5917 | Interchange |
| S-23348 | Interchange |
