Dorman 949-697 Rear Left Suspension Electronic Shock 11-16 Cadillac SRX 22857108
Confirm Fitment Before You Buy
Not sure it fits? Message Year/Make/Model/Engine (2WD/4WD if applicable) and we’ll help confirm compatibility.
Why buy from Koskowski Automotive?
• 50+ years (since 1972) • Dorman Authorized Seller • Fast shipping • Easy returns
Regular price
$429.44
Select your vehicle at the top of the page to check fitment.
Couldn't load pickup availability
Vehicle Fitment: Use the table below to match your exact configuration. If you don’t see your exact setup, message us before ordering.
This shock absorber is designed to match the fit and function of the original part on specified vehicles, and is engineered for durability and reliable performance.
- Direct replacement - this shock absorber is designed to match the fit and function of the original absorber on specified vehicles
- Restores functionality - reliable replacement for an original shock absorber that has failed due to fatigue
- Durable construction - this part is made from quality materials to ensure reliable performance and long service life
- Trustworthy quality - backed by team of product experts in the United States and more than a century of automotive experience
Vehicle Fitment
| Year | Make | Model | Position | Notes |
|---|---|---|---|---|
| 2011-2016 | Cadillac | SRX | Rear Left | w/RPO Code F45 (Real Time Chassis Damping) |
Please confirm the part number and your vehicle's year, make, model and engine before ordering. Questions? Message us with your VIN and we'll check fitment for you.
Specifications
| Brand | Dorman |
|---|---|
| Part Number | 949-697 |
| UPC | 194883487161 |
| Placement | Rear, Left |
| Color | Black |
| Type | Telescopic |
| Mounting Hardware Included | No |
| Extended Length | 541 mm |
| Lower Mount Type | Bushed Eyelet |
| Upper Mount Type | Stem |
| Boot Included | No |
| Gas Charged | No |
| Body Diameter | 53.2 mm |
| Compressed Length | 541 mm |
| Travel Length | 128 in. |
| Finish | Painted |
| Shaft Material | Steel |
| Shock Absorber Rod End Measuring Point | Top of Top Mount Assembly |
| Shock Absorber Body End Measuring Point | Center Hole of Mounting Bushing |
| Body Material | Steel |
| Rod Diameter | 19 mm |
| Body Color | Black |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 53.2 mm |
| Internal Construction Type | Single Tube |
| Grade Type | Standard Replacement |
| Cylinder Color | Black |
| Adjustable Compression | Yes |
| Dust Shield Included | Yes |
| Dust Shield Material | Plastic |
| Internal Rebound Spring | No |
| Remote Reservoir | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Strut Mount Insulator(s) Included | Yes |
| Coil Spring Insulator(s) Included | No |
| Damping Adjustment Type | Electronic |
| Includes Bump Stop | No |
| Dust Shield Diameter | 60.2 mm |
| Valving Type | Progressive |
| Adjustable Ride Height | No |
| Self-Leveling | No |
| Active or Passive Suspension | Active |
| Adjustable | Yes |
| Adjustable Damping | Yes |
| Coil Over Springs Included | No |
| Dust Shield | Yes |
| Internal Rebound Bumper | No |
| Lower Mount Code | Thru-hole |
| Package Contents | 1 Shock Absorber |
| Upper Mount Code | Stem |
| Upper Mounting Isolator Included | Yes |
| Country of Origin | China |
| Warranty | Limited Lifetime |
OE & Interchange Numbers
| 22857108 | General Motors (OE) |
|---|
