Dorman 961-049D Multi-Purpose Screw
Regular price
$12.43
Couldn't load pickup availability
Product Description
Dorman offers a comprehensive selection of screws for almost any automotive fastening job. A large selection of diameters, lengths and quantities are available in different assortments and/or kits. A multitude of thread varieties are available. Check the product details to make sure you have the right size and quantity for what you need.
- Various styles - available in many head styles including round, flat, pan, oval, truss, hex and star
- Various uses - can fasten specific areas and components of a vehicle like factory equipment or be used elsewhere that calls for a similar fastener
- Durable construction - these screws are made from quality components to ensure reliable performance and a long service life
- Trustworthy quality - backed by team of product experts in the United States and more than a century of automotive experience
Product Specifications
| ACQ Rated: | No |
|---|---|
| Callout Size: | M6-1.0 x 15 mm |
| Color: | Silver |
| Diameter: | 6 mm |
| Drive Style: | Phillips |
| Fastener Length: | 15 mm |
| Fastener Length (In): | 15 mm |
| Fastener Plating: | Geomet |
| Fastener Type: | Splash Shield Hardware |
| Finish: | Zinc |
| Finish: | Geomet |
| FQA Compliant: | No |
| Grade Type: | Standard |
| Head Diameter: | 18 mm |
| Head Drive Type: | Phillips |
| Head Shape: | Round |
| Head Tool Size: | #3 Phillips |
| Heat Hardened: | No |
| Material: | Steel |
| Overall Length: | 15 mm |
| Package Contents: | 2 Splash Shield Cover Phillips Drive Bolts |
| Package Quantity: | 2 |
| Packaging Type: | Clamshell |
| SAE or Metric: | Metric |
| Screw Grade: | Standard |
| Screw Name: | Machine Screw |
| Screw Style: | Machine Screw |
| Screw Type: | Machine Screw |
| Self Drilling: | No |
| Self Tapping: | No |
| Selling Package Quantity UOM: | Piece |
| Shank Diameter: | 12 mm |
| Shank Length: | 2 mm |
| Shoulder Diameter: | 10 mm |
| Shoulder Length: | 2.5 mm |
| Size Number: | #12 |
| Specialty: | No |
| Thread Diameter: | 6 mm |
| Thread Direction: | Clockwise |
| Thread Length: | 14.95 mm |
| Thread Pitch: | 1 mm |
| Thread Size: | M6x1.0 |
| Thread Type: | Medium |
| Type: | Splash Shield Retainer |
| Washer Attached: | No |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 90105-TBA-A00 | HONDA |
