Product Description
The original camshaft phasers on Ford's modular 5.4-liter V8 engine commonly fail from internal leaks. This timing chain kit includes a pair of upgraded Dorman OE FIX camshaft phasers, timing chains, guides, tensioners and sprocket for a complete repair.
- Complete solution - this timing chain kit includes all of the mechanical components required to change worn timing chains when replacing the failure-prone cam phasers.
- Increases durability - this kit includes a pair of patented camshaft phasers that have been redesigned to correct flaws in the original equipment phasers
- Durable construction - the components in this timing chain kit are engineered to precise specifications and manufactured from quality materials
- Quality tested - the parts in this kit have undergone try-on, corrosion and material testing to ensure a quality fit and long service life
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2014 | Ford | Expedition | V8 330 5.4L | ||
| 2014 | Lincoln | Navigator | V8 330 5.4L | ||
| 2013 | Ford | Expedition | V8 330 5.4L | ||
| 2013 | Lincoln | Navigator | V8 330 5.4L | ||
| 2013 | Lincoln | Navigator | V8 330 5.4L (5408cc) | ||
| 2012 | Ford | Expedition | V8 330 5.4L | ||
| 2012 | Lincoln | Navigator | V8 330 5.4L | ||
| 2011 | Ford | Expedition | V8 330 5.4L | ||
| 2011 | Lincoln | Navigator | V8 330 5.4L | ||
| 2010 | Ford | Expedition | V8 330 5.4L | ||
| 2010 | Ford | F-150 | V8 330 5.4L | ||
| 2010 | Ford | F-250 Super Duty | V8 330 5.4L | ||
| 2010 | Ford | F-350 Super Duty | V8 330 5.4L | ||
| 2010 | Ford | Lobo (Mexico) | V8 330 5.4L | ||
| 2010 | Lincoln | Mark LT (Mexico) | V8 330 5.4L | ||
| 2010 | Lincoln | Navigator | V8 330 5.4L | ||
| 2009 | Ford | Expedition | V8 330 5.4L | ||
| 2009 | Ford | F-150 | V8 330 5.4L | ||
| 2009 | Ford | F-250 Super Duty | V8 330 5.4L | ||
| 2009 | Ford | F-350 (Mexico) | V8 330 5.4L | ||
| 2009 | Ford | F-350 Super Duty | V8 330 5.4L | ||
| 2009 | Ford | Lobo (Mexico) | V8 330 5.4L | ||
| 2009 | Lincoln | Navigator | V8 330 5.4L | ||
| 2008 | Ford | Expedition | V8 330 5.4L | ||
| 2008 | Ford | F-150 | V8 330 5.4L | ||
| 2008 | Ford | F-250 Super Duty | V8 330 5.4L | ||
| 2008 | Ford | F-350 (Mexico) | V8 330 5.4L | ||
| 2008 | Ford | F-350 Super Duty | V8 330 5.4L | ||
| 2008 | Ford | Lobo (Mexico) | V8 330 5.4L | ||
| 2008 | Lincoln | Mark LT | V8 330 5.4L | ||
| 2008 | Lincoln | Navigator | V8 330 5.4L | ||
| 2007 | Ford | Expedition | V8 330 5.4L | ||
| 2007 | Ford | F-150 | V8 330 5.4L | ||
| 2007 | Ford | F-250 Super Duty | V8 330 5.4L | ||
| 2007 | Ford | F-350 (Mexico) | V8 330 5.4L | ||
| 2007 | Ford | F-350 Super Duty | V8 330 5.4L | ||
| 2007 | Ford | Lobo (Mexico) | V8 330 5.4L | ||
| 2007 | Lincoln | Mark LT | V8 330 5.4L | ||
| 2007 | Lincoln | Navigator | V8 330 5.4L | ||
| 2006 | Ford | Expedition | V8 330 5.4L | ||
| 2006 | Ford | F-150 | V8 330 5.4L | ||
| 2006 | Ford | F-250 Super Duty | V8 330 5.4L | ||
| 2006 | Ford | F-350 (Mexico) | V8 330 5.4L | ||
| 2006 | Ford | F-350 Super Duty | V8 330 5.4L | ||
| 2006 | Ford | Lobo (Mexico) | V8 330 5.4L | ||
| 2006 | Lincoln | Mark LT | V8 330 5.4L | ||
| 2006 | Lincoln | Navigator | V8 330 5.4L | ||
| 2005 | Ford | Expedition | V8 330 5.4L | ||
| 2005 | Ford | F-150 | V8 330 5.4L | ||
| 2005 | Ford | F-250 Super Duty | V8 330 5.4L |
Product Specifications
| Camshaft Sprocket Material: | Hardened Steel |
|---|---|
| Chain Length: | 45.5 in |
| Chain Width: | 0.52 in |
| Crankshaft Sprocket Material: | Hardened Steel |
| Keyway Adjustable: | Yes |
| Link Quantity: | 61 |
| Maximum Advance At Camshaft: | 0 deg |
| Maximum Advance at Crankshaft: | 0 deg |
| Maximum Retard at Crankshaft: | 15 Deg |
| Package Contents: | 2 Camshaft Phasers; 1 Crankshaft Sprocket; 2 Chain Guides; 2 Tensioner Arms; 2 Timing Chains; 2 Timing Chain Tensioners |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Selling Package Quantity UOM: | Kit |
| Timing Chain Type: | Link Chain |
OE Numbers
| NON-DIRECT OE CROSS | |
|---|---|
| 1L3Z6L266AA | FORD MOTOR COMPANY |
| 2L1Z6K297AA | FORD MOTOR COMPANY |
| 3R2Z 6A257-DA | FORD MOTOR COMPANY |
| 4L3Z6M256AA | FORD MOTOR COMPANY |
| 5L3Z6268A | FORD MOTOR COMPANY |
| F5RZ-6A340-B | FORD MOTOR COMPANY |
| F85Z6K255AA | FORD MOTOR COMPANY |
| F85Z6M274AA | FORD MOTOR COMPANY |
| XL1Z6L266AA | FORD MOTOR COMPANY |
| XL3Z6306AA | FORD MOTOR COMPANY |
