Dorman 986-775 Drive Shaft
Confirm Fitment Before You Buy
Not sure it fits? Message Year/Make/Model/Engine (2WD/4WD if applicable) and we’ll help confirm compatibility.
Why buy from Koskowski Automotive?
• 50+ years (since 1972) • Dorman Authorized Seller • Fast shipping • Easy returns
Regular price
$1,162.10
Couldn't load pickup availability
Vehicle Fitment: Use the table below to match your exact configuration. If you don’t see your exact setup, message us before ordering.
Product Description
Replacing a drive shaft doesn't have to be complicated. This complete drive shaft assembly is pre-balanced and ready to install with 100% new yokes, tubes, constant velocity (CV) joints and universal joints.
- Direct replacement - this drive shaft is made to the original equipment dimensions for dependable fit and performance
- 100% new - this drive shaft is made from all new components so there's no core charge or return hassle
- Ready to install - this drive shaft arrives pre-balanced to make installation quick and simple
- Serviceable construction - non-staked universal joints are designed for future serviceability
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2012 | Acura | RL | AWD | Rear | |
| 2011 | Acura | RL | AWD | Rear | |
| 2010 | Acura | RL | AWD | Rear | |
| 2009 | Acura | RL | AWD | Rear | |
| 2008 | Acura | RL | AWD | Rear | |
| 2007 | Acura | RL | AWD | Rear | |
| 2006 | Acura | RL | AWD | Rear | |
| 2005 | Acura | RL | AWD | Rear |
Product Specifications
| Axle Nut Included: | No |
|---|---|
| Collapsed Length (Flange Face To Flange Face): | 80.125 in |
| Collapsed Length (Yoke To Bearing): | 36.625 in |
| Collapsed Length (Yoke To Flange Face): | 80.125 in |
| Compressed Length: | 80.125 in |
| CV Joints Included: | Yes |
| Drive Shaft Length (In): | 82.125 in |
| Drive Shaft Wall Thickness (In): | 0.065 in |
| End 1 Type: | Bolt On |
| End 2 Type: | Bolt On |
| Grade Type: | Regular |
| Grease Fitting Included: | No |
| Greaseable Drive Shaft: | No |
| Max Slip: | 2 in |
| Multi Piece Shaft: | Yes |
| Overall Length Adjustable: | Yes |
| Package Contents: | 1 Driveshaft |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Phased: | No |
| Pre-Greased: | Yes |
| Shaft Diameter: | 2.5 in |
| Shaft Material: | Steel |
| Slip Yoke: | No |
| Universal Joints Included: | Yes |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 40100SJA010 | HONDA |
| 40100SJA020 | HONDA |
| 40100SJA030 | HONDA |
| 40100SJAE01 | HONDA |
| 40100SJAE02 | HONDA |
