Dorman M105801 Master Cylinder
Regular price
$65.70
Couldn't load pickup availability
Product Description
This brake master cylinder is precision-engineered to match the design, function, and performance of the original master cylinder on specific vehicle years, makes and models. It is made of new, high-quality materials for a safe, durable replacement.
- Precise replacement - cylinder housing is constructed to match the casting material of the original part and ensure similar performance
- Durable design - all rubber components are made of high-quality EPDM compound for resistance to glycol-based brake fluid
- 100% new - made entirely of new materials, not remanufactured, to ensure highest quality and safety
- Strict specifications - made to meet rigorous SAE International standards
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 1988 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1988 | Chevrolet | S10 Blazer | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1988 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1988 | GMC | S15 Jimmy | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1987 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1987 | Chevrolet | S10 Blazer | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1987 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1987 | GMC | S15 Jimmy | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1986 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1986 | Chevrolet | S10 Blazer | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1986 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1986 | GMC | S15 Jimmy | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1985 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1985 | Chevrolet | S10 Blazer | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1985 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1985 | GMC | S15 Jimmy | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1984 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1984 | Chevrolet | S10 Blazer | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1984 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1984 | GMC | S15 Jimmy | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1983 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1983 | Chevrolet | S10 Blazer | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1983 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1983 | GMC | S15 Jimmy | w/Manual Brakes; Bore: 24 mm and 31.6 mm | ||
| 1982 | Buick | Regal | Power Brakes; GAS | Bore: 24 mm and 31.6 mm | |
| 1982 | Buick | Riviera | Power Brakes; GAS; Rear Drum Brakes | Bore: 24 mm and 31.6 mm | |
| 1982 | Chevrolet | El Camino | Power Brakes | Bore: 24 mm and 31.6 mm | |
| 1982 | Chevrolet | Malibu | Stamped-18008348 | ||
| 1982 | Chevrolet | Monte Carlo | Power Brakes; GAS | Bore: 24 mm and 31.6 mm | |
| 1982 | Chevrolet | S10 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1982 | GMC | Caballero | Power Brakes | Bore: 24 mm and 31.6 mm | |
| 1982 | GMC | S15 | Manual Brakes | Bore: 24 mm and 31.6 mm | |
| 1982 | Oldsmobile | Cutlass Calais | Power Brakes; GAS | Bore: 24 mm and 31.6 mm | |
| 1982 | Oldsmobile | Cutlass Cruiser | Power Brakes; GAS | Bore: 24 mm and 31.6 mm | |
| 1982 | Oldsmobile | Cutlass Supreme | Power Brakes; GAS | Bore: 24 mm and 31.6 mm | |
| 1982 | Pontiac | Bonneville | Power Brakes; GAS | Bore: 24 mm and 31.6 mm | |
| 1982 | Pontiac | Grand Prix | Power Brakes; GAS | Bore: 24 mm and 31.6 mm |
Product Specifications
| Master Cylinder Bore Diameter: | 24 mm and 1-1/4 in |
|---|---|
| Master Cylinder Material: | Cast Iron |
| Mounting Hardware Included: | No |
| Number of Outlets: | 2 |
| Package Contents: | Master Cylinder |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Rearward Outlet Size: | 1/2-20 |
| Reservoir Included: | Yes |
| Sensor Included: | No |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 18009371 | GENERAL MOTORS |
| 18009372 | GENERAL MOTORS |
| 18009811 | GENERAL MOTORS |
| 18013421 | GENERAL MOTORS |
| 18013432 | GENERAL MOTORS |
