Dorman M630075 Master Cylinder
Regular price
$158.93
Couldn't load pickup availability
Product Description
This brake master cylinder is precision-engineered to match the design, function, and performance of the original master cylinder on specific vehicle years, makes and models. It is made of new, high-quality materials for a safe, durable replacement.
- Precise replacement - cylinder housing is constructed to match the casting material of the original part and ensure similar performance
- Durable design - all rubber components are made of high-quality EPDM compound for resistance to glycol-based brake fluid
- 100% new - made entirely of new materials, not remanufactured, to ensure highest quality and safety
- Strict specifications - made to meet rigorous SAE International standards
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2008 | BMW | Z4 | 2.5si Submodel | ||
| 2008 | BMW | Z4 | 3.0si Submodel | ||
| 2008 | BMW | Z4 | Coupe 3.0si Submodel | ||
| 2008 | BMW | Z4 | Roadster 3.0i Submodel | ||
| 2008 | BMW | Z4 | Roadster 3.0si Submodel | ||
| 2007 | BMW | Z4 | 2.5si Submodel | ||
| 2007 | BMW | Z4 | 3.0si Submodel | ||
| 2007 | BMW | Z4 | Coupe 3.0si Submodel | ||
| 2007 | BMW | Z4 | Roadster 3.0i Submodel | ||
| 2007 | BMW | Z4 | Roadster 3.0si Submodel | ||
| 2006 | BMW | 325Ci | Bore: 22 mm and 23 mm | ||
| 2006 | BMW | 330Ci | Coupe | Bore: 22 mm and 23 mm | |
| 2006 | BMW | Z4 | 2.5i Submodel | ||
| 2006 | BMW | Z4 | 3.0i Submodel | ||
| 2006 | BMW | Z4 | Coupe 3.0si Submodel | ||
| 2006 | BMW | Z4 | Roadster 3.0i Submodel | ||
| 2006 | BMW | Z4 | Roadster 3.0si Submodel | ||
| 2005 | BMW | 325Ci | Bore: 22 mm and 23 mm | ||
| 2005 | BMW | 325i | w/Dynamic Stability Control; Bore: 22 mm and 23 mm | ||
| 2005 | BMW | 330Ci | Coupe | Bore: 22 mm and 23 mm | |
| 2004 | BMW | 325Ci | Bore: 22 mm and 23 mm | ||
| 2004 | BMW | 330Ci | Coupe | Bore: 22 mm and 23 mm | |
| 2003 | BMW | 325Ci | Bore: 22 mm and 23 mm | ||
| 2003 | BMW | 330Ci | Coupe | Bore: 22 mm and 23 mm | |
| 2002 | BMW | 325Ci | Bore: 22 mm and 23 mm | ||
| 2002 | BMW | 330Ci | Bore: 22 mm and 23 mm | ||
| 2002 | BMW | 330i | w/Dynamic Stability Control | ||
| 2001 | BMW | 325Ci | Bore: 22 mm and 23 mm | ||
| 2001 | BMW | 325i | From 3/01; w/Dynamic Stability Control; Bore: 22 mm and 23 mm | ||
| 2001 | BMW | 330Ci | Bore: 22 mm and 23 mm |
Product Specifications
| Master Cylinder Bore Diameter: | 22 mm; 23 mm |
|---|---|
| Master Cylinder Material: | Aluminum |
| Mounting Hardware Included: | No |
| Number of Outlets: | 4 |
| Package Contents: | Master Cylinder |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Primary Outlet Thread Pitch: | 1 mm |
| Rearward Outlet Size: | M12 X 1.0 |
| Reservoir Included: | No |
| Secondary Outlet Thread Diameter: | M12 X 1.0 |
| Sensor Included: | No |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 34 31 6 752 540 | BMW |
| 34 31 6 770 917 | BMW |
| 34 31 6 776 002 | BMW |
| 34 33 6 779 680 | BMW |
| 34 33 6 785 666 | BMW |
