Dorman M630659 Master Cylinder
Regular price
$88.17
Couldn't load pickup availability
Product Description
This brake master cylinder is precision-engineered to match the design, function, and performance of the original master cylinder on specific vehicle years, makes and models. It is made of new, high-quality materials for a safe, durable replacement.
- Precise replacement - cylinder housing is constructed to match the casting material of the original part and ensure similar performance
- Durable design - all rubber components are made of high-quality EPDM compound for resistance to glycol-based brake fluid
- 100% new - made entirely of new materials, not remanufactured, to ensure highest quality and safety
- Strict specifications - made to meet rigorous SAE International standards
Detailed Applications
| Year | Make | Model | Configuration | Positions | Application Notes |
|---|---|---|---|---|---|
| 2013 | Toyota | Matrix | AWD; AWD Submodel | ||
| 2013 | Toyota | Matrix | AWD; S Submodel | ||
| 2013 | Toyota | Matrix | FWD; S Submodel | ||
| 2013 | Toyota | Matrix | FWD; XRS Submodel | ||
| 2012 | Toyota | Matrix | AWD; AWD Submodel | From 6/12 | |
| 2012 | Toyota | Matrix | AWD; S Submodel | From 6/12 | |
| 2012 | Toyota | Matrix | FWD; S Submodel | From 6/12 | |
| 2012 | Toyota | Matrix | FWD; XRS Submodel | From 6/12 | |
| 2010 | Pontiac | Vibe | L4 2.4L (2362cc) | ||
| 2009 | Pontiac | Vibe | L4 2.4L (2362cc) | To 1/31/09 | |
| 2009 | Toyota | Corolla | w/Vehicle Stability Control; To 1/09 | ||
| 2009 | Toyota | Matrix | FWD; Base Submodel | w/Vehicle Stability Control; To 2/09 | |
| 2009 | Toyota | Matrix | FWD; XR Submodel | w/Vehicle Stability Control; To 2/09 | |
| 2008 | Toyota | Corolla | L4 1.8L (1794cc) | From 1/08; w/Vehicle Stability Control | |
| 2008 | Toyota | Matrix | L4 1.8L (1794cc) | Built in Japan; To 1/08; w/Vehicle Stability Control | |
| 2008 | Toyota | Matrix | L4 1.8L (1794cc) | From 1/08; w/Vehicle Stability Control |
Product Specifications
| Master Cylinder Bore Diameter: | 0.875 in |
|---|---|
| Master Cylinder Material: | Aluminum |
| Mounting Hardware Included: | No |
| Number of Outlets: | 2 |
| Package Contents: | Master Cylinder |
| Package Quantity: | 1 |
| Packaging Type: | Box |
| Primary Outlet Thread Pitch: | 1 mm |
| Rearward Outlet Size: | M10 X 1.0 |
| Reservoir Included: | Yes |
| Secondary Outlet Thread Diameter: | M10 X 1.0 |
| Sensor Included: | Yes |
OE Numbers
| DIRECT OE CROSS | |
|---|---|
| 19184340 | GENERAL MOTORS |
| 19205209 | GENERAL MOTORS |
| 4720102480 | TOYOTA |
| 4720102481 | TOYOTA |
| 4720102483 | TOYOTA |
| 4720112B10 | TOYOTA |
